Cultural · 2024
Nord Pavilion
A concrete-and-oak pavilion for a coastal sculpture park, built around a single top-lit gallery. The plan is deliberately simple — one room, one route, one source of light — so the work on show, and the weather moving across the terrace outside, stay the loudest things in the building.
The brief
A gallery for changing sculpture, on a site where the weather is the permanent exhibit.
The park needed a single room that could hold work of very different scales, be lit without spotlights, and stay open through a Skagen winter. The client asked for something that would not compete with the dunes, and that a guard could run alone.
The approach
We answered with one move: a top-lit concrete room wrapped in a thin oak-and-glass skin. The rooflight runs the full length of the plan, so light arrives from above and the walls stay free for the work.
Concrete is cast in board-marked panels and left alone; oak is untreated and will darken with the salt air. Where the two meet, the junction is drawn thin and honest in blackened steel — the same three materials, in the same order, at every scale of the building.
Project facts
Location
Skagen, DK
Year
2024
Scale
640 m²
Role
Architecture & interiors
Client
Skagen Kunstpark
Status
Completed
Partner in charge
Erik Marklund
Photography
Atelier Nord
Plan
One room, one route, one source of light.
The plan is a single rectangle. Visitors enter at the low end, walk the length of the rooflight and leave onto the terrace facing the sea. Services, store and a small office sit in a thickened wall so nothing interrupts the room.
01
Gallery, top-lit
02
Thickened service wall
03
Terrace to the sea
Ground floor plan
1 : 200
Daylight
The rooflight does the work a hundred fittings would do worse.
North light is even and slow. It washes the concrete soffit, drops down the walls and lands on the floor with almost no shadow — which is exactly what a sculpture wants. On overcast days the room simply gets quieter.
Down to the last detail
Three junctions, drawn full size.
Design intent is protected in the details, and details are decided on site. These are the three we spent the most time on.
01
Rooflight to soffit
The glazing sits in a blackened steel channel so the concrete edge reads as a single thin line.
02
Board-marked concrete
Panels are 900 mm wide, set out from the centre of the room so the joints land on the door.
03
Oak threshold
Solid oak, 60 mm, laid untreated. It is already darker than the day we opened.
Gross floor area
Months from brief to opening
Materials, in the same order everywhere
Rooflight, the full length of the plan
“
